Shropshire Union Canal

The Shropshire Union Canal runs from Autherley Junction near Wolverhampton on the Staffordshire & Worcestershire Canal to the Manchester Ship Canal at Ellesmere Port.

Shropshire Union Canal Map

Hurleston lock flight
Bridge 25, Middlewich Branch

Facts & Stats

66.5 miles

(107km)

The length of the main line of the Shropshire Union Canal. The Middlewich Branch is 10 miles (16.1km) and the River Dee branch is 0.25 miles (0.4km).

47 locks

Main line

The Middlewich Branch has 4 locks and the River Dee Branch has 3 locks.

1846

Formation

Shropshire Union Railways and Canal Company was formed.

From Autherley Junction to the Manchester Ship Canal

The Shropshire Union Canal includes two navigable branches, the Middlewich Branch and the River Dee Branch.

The Middlewich Branch runs from Barbridge Junction to the Trent & Mersey Canal at Middlewich, whilst the River Dee Branch runs from the main line at Chester to the tidal River Dee.

There is also a Newport Branch, which is derelict but under restoration as part of the Shrewsbury and Newport Canals, which joins at Norbury Junction.

The Shropshire Union Canal was formed from a group of canal companies, which became the Shropshire Union Railways and Canal Company in 1846.

[The photo shows Nantwich Aqueduct  –  by Edd Leetham]

Waterway notes

Maximum boat sizes (from Autherley Junction to Nantwich)

  • Length: 70′ 11″ (21.62 metres) – Autherley Stop Lock
  • Beam: 7′ 7″” (2.21 metres) – Autherley Stop Lock
  • Height: 7′ 11″ (2.41 metres) – Bridge Lock
  • Draught: 4′ 1″ (1.24 metres) – cill of Autherley Junction Stop Lock

Maximum boat sizes (Old Chester Canal and Middlewich Branch)

Old Chester Canal

  • Length: 75′ 2″ (22.91 metres) – Ellesmere Port Locks
  • Beam: 11′ 1″ (3.37 metres) – M53 Bridge
  • Height: 7′ 11″ (2.41 metres) – Sellar Street Bridge (Bridge 123C), Chester
  • Draught: 4′ 1″ (1.24 metres) – Sellar Street Bridge

Middlewich Branch

  • Length: 75′ 4″ (22.95 metres) – Church Minsull Lock
  • Beam: 7′ 1″ (2.16 metres) – Church Minsull Lock
  • Height: 8′ 0″ (2.44 metres) – rail bridge at Cholmondeston
  • Draught: 4′ 10″ (1.47 metres) – Church Minsull Lock
